Telemetry Ground Systems
DataHUB 1U
The 3rd generation DataHUB product line is a standards-based telemetry ground system with IRIG 106 Chapter 10 record, reproduce, publish & subscriber capability. The CPAS-6010 DataHUB is a 1U, 19” rackmount system that provides (4) or (8) B-Directional PCM channels, (2) analog input channels, (4) RS-232 Rx/Tx UART channels, (1) video input channel & (3) SFP Ethernet channels. High speed data recording is provided using (2) NVMe Solid State Drives providing a total recording/reproducing bandwidth of up to 6GB per second.
DataHUB 2U
The 3rd generation DataHUB product line is a standards-based telemetry ground system with IRIG 106
Chapter 10 record, reproduce, publish & subscriber capability. The CPAS-6020 DataHUB is a 2U, 19”
rackmount system that provides (12) or (24) Bi-Directional PCM channels (422 and TTL), (4) Rx/Tx UART
channels, & (3) SFP Ethernet channels. High speed data recording is provided using (2) NVMe or SATA III
Data Drives.
DataHUB Portable
The 3rd generation DataHUB product line is a standards-based telemetry ground system with IRIG 106 Chapter 10 record, reproduce, publish & subscriber capability. The CPAS-6005 DataHUB is a 12VDC Portable system that provides (4) Bi-Directional TTL/422 channels, (2) analog input channels, (4) Rx/Tx UART channels, & (1) SFP Ethernet channel. Optional data recording is provided using a removable CFast Solid State Drive.
NetView Data Fusion & Display Software
Provides real-time decoding, processing, display and distribution from multiple IRIG 106 Chapter 10 data sources (including DataHUB’s) and other network-based instrumentation systems. It decodes, time aligns, processes and displays multiple independent data source types and formats in a single processing and display environment. NetView capabilities are extended with a complete SDK allowing the user to develop their own custom GUI displays and access the data structure for end user defined decoders and special processing of measurements.
