RDMS™ Compact Receivers
Quasonix’s multi-mode compact RDMS™ telemetry receiver features an extremely sensitive RF downconverter integrated with the company’s market-leading ARTM demodulator and bit synchronization in a compact 12 cubic inch flight-ready package. When compared to the competition, RDMS™ offers a remarkable 6 to 8 dB sensitivity advantage. What you choose to do with the extra link margin is up to you.
RDMS 1U Rackmount Receiver
The highest performing telemetry receiver on the market is available in an elegant, compact 1U rack mount package and a new 3U touchscreen package. Configurations include one or two channels, diversity combining, contiguous tuning, spectrum display, adaptive equalizer, and decoding for SOQPSK Space Time Coded and Low Density Parity Check encoded signals.
RDMS 3U Rackmount Receiver
The highest performing telemetry receiver on the market is available in an elegant, compact 1U rack mount package and a new 3U touchscreen package. Configurations include one or two channels, diversity combining, contiguous tuning, spectrum display, adaptive equalizer, and decoding for SOQPSK Space Time Coded and Low Density Parity Check encoded signals.
Ethernet via Telemetry
Airborne EVTM Encoder/Decoder
With the Quasonix Ethernet Via Telemetry (EVTM) system, your test article can be on your ground station LAN, just like any other computer or Ethernet appliance. With an Ethernet switch in your test article, you can connect cameras, Voice over IP, computers, and more to your network on the ground.
-
Add Ethernet capabilities to existing airborne systems
-
Flight ruggedized design
-
Compatible with any transmitter
Rackmount EVTM Encoder/Decoder
With the Quasonix Ethernet Via Telemetry (EVTM) system, your test article can be on your ground station LAN, just like any other computer or Ethernet appliance. With an Ethernet switch in your test article, you can connect cameras, Voice over IP, computers, and more to your network on the ground.
-
Used for transmit or receive
-
Two channels with separate Ethernet connections
-
Compatible with any receiver or transmitter
EVTM Node Controller
With the Quasonix Ethernet Via Telemetry (EVTM) system, your test article can be on your ground station LAN, just like any other computer or Ethernet appliance. With an Ethernet switch in your test article, you can connect cameras, Voice over IP, computers, and more to your network on the ground.
-
Can be integrated with existing Quasonix receivers and transmitters
-
Allows for TDD (Time Division Duplex) or FDD (Frequency Division Duplex) operation
-
Smart router and data flow controls (IP addressable)
-
With or without RF switch module
Compact Airborne EVTM Transceiver
Quasonix transceivers are an essential component of our Ethernet Via Telemetry (EVTM) system, allowing for unidirectional and bi-directional transmission and demodulation of encoded Ethernet data.
RDMS Ethernet-Enabled Compact Receiver
Quasonix transceivers are an essential component of our Ethernet Via Telemetry (EVTM) system, allowing for unidirectional and bi-directional transmission and demodulation of encoded Ethernet data.
-
Built on proven RDMS receiver hardware
-
Ethernet or serial data in same package
Rackmount EVTM Transceiver
Quasonix transceivers are an essential component of our Ethernet Via Telemetry (EVTM) system, allowing for unidirectional and bi-directional transmission and demodulation of encoded Ethernet data.
-
Fully functional ground station receiver
-
Separate Ethernet connections for remote control and payload data
Test Equipment
RDMS Status Logger
Need a powerful way to analyze receiver/demodulator mission dynamics? The Quasonix RDMS™ Status Logger is the solution. View metrics in a real-time graphics display and log status information to a file.
A 1U interface unit provides for up to four (4) RDMS™ connections simultaneously.
Compact Status Logger
Need a powerful way to analyze receiver/demodulator mission dynamics? The Quasonix RDMS™ Status Logger is the solution. View metrics in a real-time graphics display and log status information to a file.
The Compact Status Logger provides an interface between an available USB port on your PC and the 25 pin control port on the rear panel of an RDMS™ receiver.
Rackmount Receiver Analyzer
With two complete ARTM signal generators covering 200 MHz to 2500 MHz and 4.4 GHz to 5.25 GHz contiguously and power levels from 0 dBm to –130 dBm, the Receiver Analyzer automates a wide range of receiver and combiner performance tests including bit error rate, noise figure, acquisition time and threshold, combiner break frequency, and PCM/FM modulation index tests. Eight bit error rate testers include integrated synchronization detection/timing and bit clock frequency counters.
Accessories
Airborne Receiver Heat Sink
Heat sink for 3″ x 4″ compact (airborne) receiver. Does not require a power source.
MDM-15 RS-422 and TTL Wiring Harness for RDMS
Male MDM-15 connector wiring harness with banana plugs for power and ground, BNC connectors for TTL clock and data, and a DB-9 connector for serial control. The cable is 35 to 36 inches long depending on the connectors. For use with compact receivers.
